Drawings Wire Machine For Nails Making
Drawings wire machine for nails making
The function of wire drawing machine is to reduce the diameter and shape of a wire using a series of dies. It achieves this by passing the wire through consecutive dies, each with a smaller hole diameter than the previous one.
As the wire is pulled through the dies, it becomes longer and thinner, resulting in improved tensile strength and a smoother surface finish. the finished product after drawing can be used for making nails, binding wire, wire mesh, welded mesh etc.
| Model | LZ-560 |
| Raw material | Low carbon steel wire,wire tensile strength≤550MPa |
| Number of blocks | depends on your input wire dia. and output dia. |
| Input wire diameter | 8.0mm,6.5mm,5.5mm,etc. |
| Output wire diameter | 4mm,3mm,2.5mm,2.2mm,2mm,1.8mm,1.6mm etc. |
| Each motor capacity | 22kw/30kw/37kw |
| Drawing speed | 15-20M/min |
| Each block weight | 2000KGS |
Products Feature
Drawings wire machine for nails making
1. Rotary die box for extending drawing die life and make the wire more round
2. ZG45 cast steel drum with 80mm high tungsten carbide coating, 22000hours working life.
3. Water cooling inside the drawingdrums to cooling down the temp.
4. Drawing blocks adopts reducer &synchronous belt, working speed is higher. And we use37kw motor for high temperature countries.
5. With Cold rolling ribbing cassette, you can make both smooth wire and ribbed wire.
Company profile
Hebei Hylite Machinery Co., Ltd. is located in the center of the Beijing-Tianjin-Hebei economic & technological region - Xianxian Economic Development Zone, where is the birthplace of motto "Seeking Truth From Facts". The factory covers an area of 50 acres. We are engaged in the R&D, manufacturing and sale service of equipment for steel bar and metallic wire processing.
*Has many years of rich experience in steel processing equipment, has a professional R & D team and after-sales service team based on Italian designers, the production of a variety of direct wire drawing machine, horizontal wire drawing machine, high-speed cold rolling ribbed steel equipment, steel stranding equipment, steel stranding equipment, PC steel rod equipment, welding wire equipment, steel stranding machine and other large and medium-sized steel processing equipment can be customized.
