Model 12 Multi-wheel straightener Parameter
|
Wire diameter |
5-12mmhot rolled wire rods HRB335, HRB400, HRB500 5-12mm cold rolled coiled bar |
|
Speed of straightening |
0-120m/min |
|
Output length |
10-12000mm |
|
Tolerance |
≤3mm per meter |
|
Tolerance in length |
±5mm |
|
Rated power |
Main motor: 22Kw Huite Motor Cutting: 15Kw |
|
Straightening mechanism |
Continuous roller straightening with two rows of straightening wheels, Basically no damage to longitudinal rib, The main body is full tooth structure, oil bath lubrication |
|
Cutting device |
Servo flying cutting |
|
Control system |
VFD, PLC, Servo Brand: Yingweiteng |
