Flux-cored Welding Wires Production Line

Flux-cored Welding Wires Production Lines

Flux-cored welding wire is a rapidly developed welding material in recent years, because of its incomparable advantages of other welding materials: such as high efficiency, excellent process, less splash, high welding quality, easy to achieve automation, etc., has been widely used in industrial developed countries.
This Flux-cored Welding Wires Production Lines, we use the current very mature strip steel for the production of flux-cored wire. The strip forming process has the advantages of simplicity, reliability and low cost. Currently, more than 90% of the flux cores are made by this method.

Flux-cored Welding Wires Production Lines

Flux-cored wire production process:
Cartridge → powder mixing → Powder addition → Strip steel → strip coiling → coiling wire forming equipment → Drawing → winding into a 15kg coil → Packing

Finished product specification: Φ2.55mm-Φ2.31mm (semi-finished flux-cored wire), after stretching again can reach Φ1.6mm-Φ1.2mm
Steel strip material: Mild steel SPCC-SD
Feeding mode: belt feeding (controlled by mechanical transmission speed feedback system)
Variable frequency speed regulation,PLC control
Photoelectric powder free automatic detection system, powder free alarm

Flux-cored welding wire production equipment composition:
1. Strip slitter
2. I-wheel
3. Steel strip pay-off machine
4. Cleaning machine
5. Small crane
6. I-wheel take-up machine
7. Cartridge Cartridge
8. Flux-cored welding wire forming equipment includes electric control cabinet
9. Opening rack
10. LZ-10/400 direct wire drawing machine
11. Tensioning device
12. Receiving rack
13. LZ-9/400 direct wire drawing machine
14. Layer winding machine.









Flux-cored Welding Wires Production Lines

Advantages

European Standard

Our quality management confirms to European standard in the aspect of equipment performance, production capacity, quality and service life.

Italian R&D Team

Independent R&D team consist of Italian and Chinese professors and engineers. One of the first research team in China of wire processing equipment.

Manufacturing Plant

Hebei Hylite has its own manufacturing plant in China with more than 20 years history and strong supply capacity.

Worldwide Service

Installation & commissioning service available in most countries on the earth. Our technicians can reach your location within 48 hours.

All key spare parts of the company are independently produced by us to control their processing accuracy and quality, thereby extending the service life of the machinery.The company has taken the lead in passing the ISO9001:2008 quality system certification and the EU CE product safety certification in the same industry, providing reliable assurance for excellent product quality.

The company's machinery and equipment sell well in China, and are exported more than 100 countries and regions such as Romania, Lithuania, Turkey, Poland, Belarus, Ukraine, Russia, Kazakhstan, Saudi Arabia, Egypt, Algeria, South Africa,Vietnam, Thailand, India, Pakistan, Philippines, Indonesia, Australia, Mexico, Colombia, Argentina, Bolivia, Brazil, etc.After more than ten years of development, the company has grown into one of the leading enterprises in the industry. We adhere to the tenet of "customer first, technology leading". In the future, the company will comprehensively promote industrial development and upgrading, and build the word's leading steel processing equipment.
