Automatic Hot Dip Steel Bar Galvanizing Equipment - Rebar Galvanizing Production Line

Galvanized steel bars are coated with a layer of zinc on the surface of ordinary steel bars, mainly achieved through methods such as electroplating and hot plating. The main characteristics of galvanized steel bars are as follows.

Send Inquiry

Product Introduction

Automatic Continuous Hot-Dip Galvanizing Equipment for Steel Bars & Rebar

Turnkey industrial continuous hot-dip galvanizing production line engineered for steel bars, reinforcing rebar, and structural steel rods. Features automated pre-treatment pickling, fluxing, drying, ceramic zinc kettle immersion, automated air-knife zinc coating thickness wiping, and immediate water quenching for superior anti-corrosion performance.

Ceramic Induction Zinc Kettle

Internal ceramic lined zinc bath with submerged induction heating prevents kettle iron dissolution and extends bath life over 10 years.

Air-Knife Thickness Regulators

High-pressure annular air knives wipe excess molten zinc, delivering uniform coating weights from 300 to 900 g/m².

Automated Continuous Feed

Roller conveyor system transports steel bars smoothly through fluxing, pre-heating, and zinc immersion baths.

Enclosed Acid & Zinc Fume Scrubber

Full-enclosure hoods with wet scrubber towers neutralize hydrochloric acid fumes and zinc smoke for clean factory air.

Engineering Specifications & Technical Data

Galvanizing Line Field	Technical Benchmark
Processed Material Range	Deformed rebar (Φ8mm - Φ32mm), smooth steel bars (Φ10mm - Φ50mm), threaded rods
Bar Length Capacity	6 meters - 12 meters standard length (Customizable for up to 15m bars)
Zinc Coating Standard	ISO 1461, ASTM A123, ASTM A767 / A767M Class I & Class II
Zinc Coating Thickness	45 μm - 125 μm (320 - 900 g/m² zinc weight)
Zinc Kettle Temperature	440°C - 460°C with PID automatic heating control (±2°C)
Production Line Capacity	10,000 to 50,000 Metric Tons per Year
Heating Source Options	Natural gas burners, LPG, or electric induction immersion heaters

Core Design & Operational Advantages

Superior Rebar Bond Strength: Hot-dip zinc coating forms metallurgically bonded iron-zinc alloy layers with zero flaking during rebar bending.
Automated Zinc Dross Skimmer: Mechanical skimming arm automatically sweeps top zinc dross to maintain mirror-smooth bar finish.
Inline Passivation Quench Tank: Chromate-free passivation bath prevents white rust storage staining during sea freight.

Buyer Inquiries & Technical FAQ

Q: Does hot-dip galvanizing meet ASTM A767 standards for bridge and marine concrete rebar?
A: Yes, our continuous line fully complies with ASTM A767 Class I (1070 g/m²) and Class II (610 g/m²) requirements for heavy marine infrastructure.

Q: How does the ceramic kettle compare with traditional steel zinc kettles?
A: Ceramic kettles eliminate zinc-iron alloy dross formation caused by kettle wall erosion, saving up to 15% zinc consumption and lasting 3x longer.

Consult With Our Senior Engineering Team

Get customized production calculations, 3D factory layout drawings, and direct factory pricing within 24 hours.

Request Hot-Dip Rebar Galvanizing Plant Proposal
